SN-S Laboratory Ultrasonic Cleaning Machine
SN-S Laboratory Ultrasonic Cleaning Machine
SN-S Laboratory Ultrasonic Cleaning Machine
SN-S Laboratory Ultrasonic Cleaning Machine
SN-S Laboratory Ultrasonic Cleaning Machine

Model NO.: SN-S

SN-S Laboratory Ultrasonic Cleaning Machine

Laboratory ultrasonic cleaning machine is a specialized equipment for cleaning medical equipment, laboratory vessels, industrial parts. Its characteristic is that it has a single cleaning tank, which is filled with cleaning solution. The ultrasonic generator generates high-frequency ultrasonic waves, causing the cleaning solution to produce dense small bubbles and rupture, generating impact force and micro flow. It can efficiently remove dirt, bacteria and pollutants from the surface and microstructure of items, ensuring thorough cleaning and disinfection

Product Feature

Exquisite appearance sturdy and square body, beautiful and easy to clean;
Residual free inner liner Made of SUS304 stainless steel, the inner liner is smooth, liquid free, and corrosion-resistant;
Power outage protection working parameter memory, automatic protection function;
Adjustable time 1-960 minutes of working time setting, long-term continuous work;
Adjustable power Linear adjustment of 0% -100%;
Heating function PID algorithm control, heating temperature can reach up to 95° C;
LCD screen inch intelligent touch screen, clear display;
Ultrasonic system professional grade transducer, capable of emitting waves in all directions;
Safety protection temperature control, grounding, overvoltage, overcurrent, air switch protection;
Temperature control protection high-precision PID control, temperature difference within ±2 °C;
Pulse degassing intermittent frequency modulation pulse work, discharge bubbles, improve ultrasonic cavitation effect;
Intelligent storage 10 groups operation program data storage.


Product ModelInner tank size/volumeOuter cladding materialInner groove materialControl methodcapacityfrequencyUltrasonic powerHeating powerTime ControltemperatureVoltageMaximum power of the whole machineInlet and outlet sizeStandard wire
SN-38S500*300*250mm201/T0.8304 T2.0 No residueTouch 5 inches38L40KHz600W1.5KW0-960minNormal temperature -95C°220V single phase2.1KW6 points1.5 m
SN-53S500*350*300mm201/T0.8304 T2.0 No residueTouch 5 inches53L40KHz900W1.5KW0-960minNormal temperature -95C°220V single phase2.4KW6 points1.5 m
SN-77S550*400*350mm201/T0.8304 T2.0 No residueTouch 5 inches77L40KHz1200W3KW0-960minNormal temperature -95C°220V single phase4.2KW6 points1.5 m
SN-99S550*450*400mm201/T0.8304 T2.0 No residueTouch 5 inches99L40KHz1500W3KW0-960minNormal temperature -95C°220V single phase4.5KW6 points, 1 inch1.5 m
SN-96S800*300*400mm201/T0.8304 T2.0 No residueTouch 5 inches96L40KHz1500W3kw0-960minNormal temperature -95C°220V single phase4.5KW6 points, 1 inch1.5 m
SN-135S600*500*450mm201/T0.8304 T2.0 No residueTouch 5 inches135L40KHz1800W4.5KW0-960minNormal temperature -95C°380V three-phase5.3KW6 points, 1 inch3 meters
SN-175S700*500*500mm201/T0.8304 T2.0 No residueTouch 5 inches175L40KHz2400W6KW0-960minNormal temperature -95C°380V three-phase8.4KW6 points, 1 inch3 meters
SN-264S800*600*550mm201/T0.8304 T2.0 splicing weldingTouch 5 inches264L40KHz3000W6KW0-960minNormal temperature -95C°380V three-phase9KW6 points, 1 inch3 meters
SN-360S1000*600*600mm201/T0.8305 T2.0 splicing weldingTouch 5 inches360L40KHz3600W9KW0-960minNormal temperature -95C°380V three-phase12.6KW6 points, 1 inch3 meters
SN-540S1000*900*600mm201/T0.8306 T2.0 splicing weldingTouch 5 inches540L40KHz5400W18KW0-960minNormal temperature -95C°380V three-phase23.4KW1 1/4"3 meters
SN-960S1200*1000*800mm201/T0.8307 T2.0 splicing weldingTouch 5 inches960L40KHz7200W24KW0-960minNormal temperature -95C°380V three-phase31.2KW1 1/2"3 meters
