Model NO.: SN-PTD
The multi-channel cell disruptor is an ultrasonic device used for simultaneous processing of laboratory and small batch liquids, which can safely process various organic and inorganic materials. Typical applications include nanotechnology
(Production of nano particle materials and graphene dispersions), cell lysis, sample preparation, homogenization, ChIP analysis, emulsification, depolymerization, and applications in the field of biochemical treatment.
Product Feature
| Exquisite appearance | Streamlined body, high-quality SPCC steel plate combination nano coating process, wear-resistant and beautiful; |
| Energy gathering and frequency equalization | Using an energy gathering amplification amplitude rod to uniformly amplify ultrasonic energy; |
| Flexible parameters | Time/power can be flexibly set; |
| LCD screen | 7-inch LCD touch screen, clear operation, real-time display of broken data; |
| Automatic frequency tracking | Self-developed scanning frequency tracking scheme, real-time frequency modulation based on liquid state; |
| Electric lifting | Button control, precise positioning; |
| Intelligent storage | Capable of creating and storing 20 sets of operating programs; |
| Ultrasonic system | High energy ultrasonic system for rapid processing of cells and samples; |
| Safety protection | Automatic temperature detection, grounding, voltage and current protection, etc; |
| Noise reduction design | Fully enclosed wrapped with noise reducing cotton; |
| Program module | MCU core component, digital tracking, providing dual protection; |
| High throughput fragmentation | Multiple conversion die heads for efficient processing of multiple samples. |
| Specifications | Frequency | Display Mode | Power | Number Of Horns | Amplitude Transformer Diameter | Crushing Capacity | Interval Output Time Adjustment | Power Parameters | Workbench | Temperature Alarm | Run Time Adjustment |
| SN-P4TD | 20KHz | 7-inch touch screen display | 650W (1%-100%) | 4 | φ6 | 1-20ml | 0-9S | Single phase 220V 50Hz | Electric lift | 0-99.9°C (to prevent sample overheating) | 0-960min |
| SN-P6TD | 20KHz | 7-inch touch screen display | 1000W (1%-100%) | 6 | φ6 | 1-20ml | 0-9S | Single phase 220V 50Hz | Electric lift | 0-99.9°C (to prevent sample overheating) | 0-960min |
| SN-P8TD | 20KHz | 7-inch touch screen display | 1800W (1%-100%) | 8 | φ6 | 1-20ml | 0-9S | Single phase 220V 50Hz | Electric lift | 0-99.9°C (to prevent sample overheating) | 0-960min |
| SN-P16TD | 20KHz | 7-inch touch screen display | 2400W (1%-100%) | 16 | φ6 | 1-20ml | 0-9S | Single phase 220V 50Hz | Electric lift | 0-99.9°C (to prevent sample overheating) | 0-960min |
| SN-P24TD | 20KHz | 7-inch touch screen display | 2400W (1%-100%) | 24 | φ5 | 0.5-5ml | 0-9S | Single phase 220V 50Hz | Electric lift | 0-99.9°C (to prevent sample overheating) | 0-960min |
| SN-P48TD | 20KHz | 7-inch touch screen display | 2400W (1%-100%) | 48 | φ3 | 0.5-4ml | 0-9S | Single phase 220V 50Hz | Electric lift | 0-99.9°C (to prevent sample overheating) | 0-960min |
| SN stands for instrument, P stands for crushing, 6 stands for the number of channels, and TD stands for channel | |||||||||||
Our Knowledgeable Team is Here to Help
1. Industrial Cleaning; 2. Laboratory Cleaning and General Equipment; 3. Gene Transduction; 4. High-Throughput Screening; 5. Fermentation Optimization; 6. Sample Pretreatment; 7. Separation and Purification; 8. Sample Preparation
Customize NowSolution In Different Industrial Application
The laboratory ultrasonic machine can be used for very wide application in science research field. Included sample pretreatment, ultrasonic water bath, ultrasonic oscillation,emulsification, mixing, extraction, dispersion, elimination, degassing, cell crushing catalytic reaction, and assistance functions such as dissolution,acceleration of chemical reactions, viscosity reduction of adhesive liquids, semiconductor silicon wafers, new materials and energy, scraper extraction, Hypersonic magnetic materials and other applications.
The Mechanical Hardware Industry involves the manufacture, processing and sale of various mechanical parts. These parts are widely used in many fields such as construction, automobiles, electronics, and machinery manufacturing. The cleaning process is an important part of the mechanical hardware industry, which ensures that the parts meet the required cleaning standards before subsequent processing, assembly or use.
Medical Ultrasonic Clean Machine
Faced with the challenges posed by the most stringent standards in the medical industry, ultrasonic cleaning technology effortlessly rises to the task of cleaning during processing or reprocessing. The high-frequency vibrations generated by ultrasonic waves efficiently remove contaminants and microorganisms from instrument surfaces, ensuring medical devices meet cleanliness requirements that comply with industry regulations.
The Application of Ultrasonic Technology in Biological Research Experiments
Our products provide a range of equipment and solutions in the field of synthetic biology. From strain design, high-throughput screening (specimen processing, dynamic analysis) during the R&D phase to fermentation optimization, as well as pre-treatment for separation/purification and lyophilization preservation in the production phase. Through relevant supporting equipment, we help clients delve into the mysteries of synthetic biology and advance the development and application of synthetic biology.
Redcrown provides a variety of advanced instruments and solutions in the field of environmental protection. These equipment are widely used in environmental monitoring, pollution control, resource recovery and ecological restoration. Freeze dryer is used for soil sample drying. Ultrasonic cleaning is used for solvent treatment. Microbial growth curve analyzer is used for water pollution microbial degradation assessment. Ultrasonic cleaning is used for experimental cleanliness, etc.
In Vitro Diagnostics (IVD) refers to the analysis of human samples (e.g., blood, urine, tissues, cells) outside the body to obtain critical health information, including disease diagnosis, treatment monitoring, and prognostic evaluation. IVD technologies play a pivotal role in modern medicine, enabling early disease detection, guiding therapeutic decision-making, and assessing treatment efficacy. Redcrown provides advanced instruments and tailored solutions for the IVD sector, with applications spanning clinical testing, disease diagnostics, and scientific research.
