77-960L Fully Automatic Industrial Ultrasonic Cleaner with Conveyor & Drying System

77-960L Fully Automatic Industrial Ultrasonic Cleaner with Conveyor & Drying System

Automatic industrial ultrasonic Cleaner utilized advanced ultrasonic Technology of high-frequency ultrasonic waves (20-40 kHz) to generate cavitation bubbles, ensuring thorough removal of contaminants like grease, oil, rust, and particulates from complex surfaces and blind holes.

Fully Automated Operation: Equipped with programmable logic controllers (PLCs) and touchscreen interfaces for precise control of cleaning cycles, temperature, and drying processes, minimizing manual intervention.

Multi-Stage Cleaning System: Integrates pre-wash, ultrasonic cleaning, rinsing, hot-air drying, and anti-corrosion stages for comprehensive treatment.

Inquire Now

Product Feature

1. Durable Construction: Made of stainless steel SUS304 or corrosion-resistant alloys, suitable for harsh industrial environments and compatible with water-based or solvent-based cleaning agents.

2. Energy Efficiency: Features eco-friendly designs with closed-loop water recycling and low-power ultrasonic generators to reduce resource consumption.

3. Versatile Customization: Adjustable tank sizes, basket configurations, and modular add-ons (e.g., filtration, degassing) to accommodate parts of varying shapes and volumes.

4. Safety Compliance: Includes overload protection, leak detection, and fume extraction systems to meet international industrial safety standards.

5. Key Advantages: Enhances production efficiency, ensures consistent cleaning quality, extends equipment lifespan, and reduces hazardous waste generation. Ideal for high-volume industries requiring repeatable, contaminant-free results.

Model	Inner Size(mm)	Capacity(L)	1st Tank Parameter	2nd Tank Parameter	3rd Tank Parameter	Load-Bearing(Kg)	Machhine Size	Total Machine Power(kw)
JM-3072SD	550x450x350	77	ultrasonic 1.2kw/28khz,	ultrasonic 1.2kw/40khz,	mobile wind cutting,	20	352013801850	18
			heating 4.5kw,	heating 4.5kw,	Hot air drying,
			filtering, sub tank 1.5kw	bubbling	3kw+0.75kw blower
JM-3072SD	600x500x450	135	ultrasonic 1.8kw/28khz,	ultrasonic 1.2kw/28khz,	mobile wind cutting,	60	365014201930	30
			heating 6kw,	heating 6kw,	Hot air drying,
			filtering, sub tank 3kw	bubbling	9kw+1.5kw blower
JM-3144SD	1000x600x600	360	ultrasonic 3.6kw/28khz,	ultrasonic 3.6kw/28khz,	mobile wind cutting,	100	410015802100	56
			heating 12kw,	heating 12kw,	Hot air drying,
			filtering, sub tank 4.5kw	bubbling	15kw+1.5kw blower
JM-3216SD	1000x900x600	540	ultrasonic 5.4kw/28khz,	ultrasonic 5.4kw/28khz,	mobile wind cutting,	150	410019302100	95
			heating 24kw,	heating 24kw,	Hot air drying,
			filtering, sub tank 6kw	bubbling	24kw+3kw blower
JM-3288SD	1200x1000x800	960	ultrasonic 7.2kw/28khz,	ultrasonic 7.2kw/28khz,	mobile wind cutting,	200	438020502300	124
			heating 36kw,	heating 36kw,	Hot air drying,
			filtering, sub tank 6kw	bubbling	24kw+3kw blower

Application Effect:

Ultrasonic cleaning provides a fast and effective way to eliminate oil, grease, rust, glue, and other debris. It's particularly useful for reaching blind holes, narrow gaps, and difficult-to-access areas on different types of workpieces.

Automatic Industrial Ultrasonic Cleaner

Our Knowledgeable Team is Here to Help

1. Industrial Cleaning; 2. Laboratory Cleaning and General Equipment; 3. Gene Transduction; 4. High-Throughput Screening; 5. Fermentation Optimization; 6. Sample Pretreatment; 7. Separation and Purification; 8. Sample Preparation

Customize Now

Solution In Different Industrial Application

Redcrown's Ultrasonic technology provides companies with related instruments and equipment for biomedicine, medical care, IVD, biosafety, food safety, disease prevention and control, inspection and quarantine, environmental protection, industrial cleaning and new materials research. We provide intelligent instruments and equipment and services related to life sciences to worldwide universities and research institutions.

Laboratory Ultrasonic Machine

The laboratory ultrasonic machine can be used for very wide application in science research field. Included sample pretreatment, ultrasonic water bath, ultrasonic oscillation,emulsification, mixing, extraction, dispersion, elimination, degassing, cell crushing catalytic reaction, and assistance functions such as dissolution,acceleration of chemical reactions, viscosity reduction of adhesive liquids, semiconductor silicon wafers, new materials and energy, scraper extraction, Hypersonic magnetic materials and other applications.

Mechanical Hardware Industry

The Mechanical Hardware Industry involves the manufacture, processing and sale of various mechanical parts. These parts are widely used in many fields such as construction, automobiles, electronics, and machinery manufacturing. The cleaning process is an important part of the mechanical hardware industry, which ensures that the parts meet the required cleaning standards before subsequent processing, assembly or use.

Medical Ultrasonic Clean Machine

Faced with the challenges posed by the most stringent standards in the medical industry, ultrasonic cleaning technology effortlessly rises to the task of cleaning during processing or reprocessing. The high-frequency vibrations generated by ultrasonic waves efficiently remove contaminants and microorganisms from instrument surfaces, ensuring medical devices meet cleanliness requirements that comply with industry regulations.

The Application of Ultrasonic Technology in Biological Research Experiments

Our products provide a range of equipment and solutions in the field of synthetic biology. From strain design, high-throughput screening (specimen processing, dynamic analysis) during the R&D phase to fermentation optimization, as well as pre-treatment for separation/purification and lyophilization preservation in the production phase. Through relevant supporting equipment, we help clients delve into the mysteries of synthetic biology and advance the development and application of synthetic biology.

Environmental Protection

Redcrown provides a variety of advanced instruments and solutions in the field of environmental protection. These equipment are widely used in environmental monitoring, pollution control, resource recovery and ecological restoration. Freeze dryer is used for soil sample drying. Ultrasonic cleaning is used for solvent treatment. Microbial growth curve analyzer is used for water pollution microbial degradation assessment. Ultrasonic cleaning is used for experimental cleanliness, etc.

In Vitro Diagnosis

In Vitro Diagnostics (IVD) refers to the analysis of human samples (e.g., blood, urine, tissues, cells) outside the body to obtain critical health information, including disease diagnosis, treatment monitoring, and prognostic evaluation. IVD technologies play a pivotal role in modern medicine, enabling early disease detection, guiding therapeutic decision-making, and assessing treatment efficacy. Redcrown provides advanced instruments and tailored solutions for the IVD sector, with applications spanning clinical testing, disease diagnostics, and scientific research.
